FORLONG PROVIDES A FULL RANGE ALLOY WHEELS FOR TOURING CARAVANS
Alloy wheels for Touring Caravans from 10inch to 15 inch
We have provided the Alloy wheels for OE Caravans manufacturer since 2015, this is mainly reasons that Forlong can understand the real demand of the Europe Market.
PAINT
Corrosion resistance
Reach: Complied with the latest Reach regulation of European Chemical Agency (ECHA), Which do not contain any of the Substances of Very High Concern(209 SVHCs) listed in the Candidate List with a concentration above 0,1%.
ETRTO STANDARD
All wheels are produced according to ETRTO standard
COMPLETE WHEELS(Wheel assembly)
Forlong can provide the tyre and wheels combination.
We assemble tyres and wheel for customers with top quality pneumatic tyres, Such as LINGLONG, GOODRIDE, WESTLAKE, WANDA.
Just part of Forlong wheel listed here, for more or customization please contact us direct.
|
Wheel Size |
Assembled Tyre Size |
Bolt Hole No. |
Bold hole shape |
PCD (mm) |
Central Hole Diameter (mm) |
Offset (mm) |
Load
Capacity (140km/h) |
| 6.00X10 | 195/55R10 | 4 | ∅15.5 60° | 100 | 57.1 | 0 | 750KGS |
| 5 | ∅15.5 60° | 112 | 67.1 | 0 | 750KGS | ||
| 5 | ∅15.5 R12 | 112 | 67.1 | -4 | 750KGS | ||
| 4.00X13 | 145/80R13 | 4 | ∅15.5 60° | 98 | 58.5 | 30 | 500KGS |
| 155/70R13 | 4 | ∅15.5 60° | 100 | 57.1 | 30 | 500KGS | |
| 155/80R13 | 5 | ∅15.5 60° | 112 | 67.1 | 30 | 500KGS | |
| 165/70R13 | 5 | ∅15.5 R12 | 112 | 67.1 | 30 | 500KGS | |
| 5.00X13 |
175/70R13 185/70R13 |
4 | ∅15.5 60° | 100 | 57.1 | 30 | 500KGS |
| 5 | ∅15.5 60° | 112 | 67.1 | 30 | 500KGS | ||
| 5.00X13 |
155R13C 165R13C 185/70R13C |
4 | ∅15.5 60° | 98 | 58.5 | 30 | 750KGS |
| 4 | ∅15.5 60° | 100 | 57.1 | 30 | 750KGS | ||
| 5 | ∅15.5 60° | 112 | 67.1 | 30 | 750KGS | ||
| 5 | ∅15.5 R12 | 112 | 67.1 | 30 | 750KGS | ||
| 6.00X13 | 195/50R13C | 5 | ∅15.5 60° | 112 | 66.6 | 30 | 950KGS |
| 5 | ∅15.5 R12 | 112 | 66.6 | 30 | 950KGS | ||
| 5.50X14 | 185R14C | 5 | ∅15.5 60° | 112 | 66.6 | 30 | 950KGS |
| 195R14C | 5 | ∅15.5 R12 | 112 | 66.6 | 30 | 950KGS | |
| 6.00X14 | 205R14C | 4 | ∅15.5 60° | 100 | 57.1 | 30 | 590KGS |
| 4 | ∅15.5 60° | 100 | 57.1 | 35 | 590KGS | ||
| 5 | ∅15.5 60° | 112 | 67.1 | 30 | 590KGS | ||
| 5 | ∅15.5 60° | 112 | 67.1 | 35 | 590KGS | ||
| 5.50X15 | 205R15C | 5 | ∅15.5 60° | 112 | 66.6 | 30 | 900KGS |
| 5 | ∅15.5 R12 | 112 | 66.6 | 30 | 900KGS |
